FivePRS is a free, open-source public response framework for FiveM: police, fire and EMS roleplay in one resource, with server-side dispatch, real jurisdictions, records, civilian life and an in-car terminal.
Caution
FivePRS is in public testing. Expect bugs, and back up your database before updating. Report problems in Issues or on Discord.
The full documentation lives at fiveprs.org/docs.
- Download
fiveprs.zipfrom the latest release. - Extract it into your server's
resources/folder, so you haveresources/fiveprs/fxmanifest.lua. - Add the server configuration below to
server.cfg, ending withensure fiveprs. - Start the server. The console shows
[FivePRS] Database (SQLite) ready.and[FivePRS] ServerBrain online.
FivePRS runs on Windows and Linux servers for GTA V Legacy. It uses SQLite out of the box, so there is nothing else to set up; MySQL 8 and MariaDB 10.6+ are supported too.
Important
GTA V Enhanced isn't supported yet. FiveM for Enhanced runs C# resources on .NET 10 in a sandbox that FivePRS doesn't run in yet. Enhanced support is coming in a later release; until then, use a GTA V Legacy server.
Optional official addons (a loading screen, Discord rich presence and a Notes app) are in the addons repository: download fiveprs_addons.zip from its releases.
To update, see Updates: FivePRS tells you when a new release is out and can download it for you. What changed in each release is in the changelog.
On Windows, run publish.ps1 to build everything and package dist/fiveprs.zip. Run the tests with dotnet test.
Before a release, run tools/smoke/smoke.ps1 with Docker running and FIVEPRS_LICENSE_KEY set to a Cfx.re server key. It starts the package on a real Linux FXServer with SQLite, then with MySQL (MariaDB and oxmysql), and fails if FivePRS doesn't come online or the server crashes. Add -Build to rebuild first.
set fiveprs_db_type "sqlite" # or "mysql" (also for MariaDB; needs oxmysql, see below)
set fiveprs_db_connection "" # optional custom SQLite path
set fiveprs_max_xp 500 # cap on XP awarded per call
set fiveprs_xp_multiplier 1.0
set fiveprs_restrict_departments false # true limits departments to the ACE below or the admin roster
set fiveprs_server_icon true # use the FivePRS icon unless load_server_icon sets your own
setr fiveprs_debug false # true shows debug messages and full error details (server and F8)
add_ace group.admin fiveprs.admin allow
add_ace group.police fiveprs.department.police allow
add_ace resource.fiveprs command.load_server_icon allow # lets FivePRS set the server icon
ensure fiveprsFivePRS connects to MySQL 8 and MariaDB 10.6+ through oxmysql. Install it, then set its connection string and start it before FivePRS:
set mysql_connection_string "mysql://user:password@localhost/fiveprs?charset=utf8mb4"
set fiveprs_db_type "mysql"
ensure oxmysql
ensure fiveprsIf you used fiveprs_db_connection for MySQL before, rewrite it in the mysql://user:password@host:port/database form above for mysql_connection_string. oxmysql doesn't read every key of the old Server=…;Database=…;Password=… format.
| Permission | Grants |
|---|---|
fiveprs.admin |
Admin commands, the Admin app and access to every department |
fiveprs.department.<police|ems|fire> |
Joining that department when fiveprs_restrict_departments is true |
When fiveprs_restrict_departments is true, a player can join a department if they are an admin, hold its ACE, or are on its roster in the Admin app.
Admin commands work from the server console or in game with fiveprs.admin:
| Command | Description |
|---|---|
fprs_units |
List on-duty units and their status |
fiveprs_diag |
Print the version, platform, database, OneSync, addons and any warnings; paste it into bug reports |
fprs_setrank <id> <rank> |
Set a player's rank |
fprs_addxp <id> <amount> |
Grant XP |
fprs_setdept <id> <department> |
Move a player to a department |
fprs_offduty <id> |
Force a player off duty |
fprs_endcall <call id> |
Close an active call |
Press F5 or use /fiveprs to open the FivePRS terminal, a rugged in-car tablet. It opens on a home screen with a status bar (your callsign and status, or your active character) and an app for each feature you can use: Duty, Dispatch, Records, Characters, Licenses, Vehicles, 911, Admin and Settings. Apps only appear when you can use them, Dispatch shows a badge for an incoming or active call, and 911 shows one while your call is open. Home or Escape returns to the home screen; Escape on the home screen closes the terminal.
The Settings app holds per-player options. While on duty it has the AI callouts switch. Players choose a wallpaper from the defaults or, if allowed, paste any https image link; the choice is saved to their profile on the server.
Wallpapers are configured under terminal in config/settings.json: wallpapers lists the built-in choices (id, label, url), defaultWallpaper is the id used until a player picks one, and allowCustomWallpapers set to false limits players to that list.
Anyone can add apps to the terminal, either as a C# DLL dropped into apps/ or from any resource through exports. Both kinds get a home screen icon, a badge and the Home button, and can either describe a screen that FivePRS draws in the terminal's style, or show their own HTML page.
C# app (apps/*.net.dll). Reference client/FivePRS.Core.dll and client/FivePRS.Client.net.dll, build a net452 class library named <Name>.net.dll, and subclass TerminalApp:
using System.Collections.Generic;
using FivePRS.Client.Terminal;
using FivePRS.Core.Models;
public class TowApp : TerminalApp
{
public override string Id => "tow";
public override string Label => "Tow";
public override string Color => "#ca8a04";
public override string Icon => "M3 17h13l3-5h2v5 M7.5 19a2 2 0 1 0 0-4 2 2 0 0 0 0 4z";
public override bool IsAvailable(PlayerData player) => player.IsOnDuty;
public override AppScreen BuildScreen() => new AppScreen()
.Add(AppBlock.Section("Request a tow"))
.Add(AppBlock.Buttons(new AppItem { Title = "Call tow truck", Action = "call", Style = "primary" }));
public override void OnAction(string action, IDictionary<string, object> data)
{
if (action == "call") Refresh();
}
}Screens are built from blocks: Section, Paragraph, Buttons, List (rows or a grid, with optional images) and Form. Every button, list item and form sends its Action and Data to OnAction. Icon is SVG path data on a 24×24 grid or an image URL; Order places the app on the home screen (built-in apps use 0 to 80, Settings is 1000); Badge shows a badge. For a fully custom screen, set Page to an HTML file such as apps/tow/index.html and put the page in apps/tow/.
Resource app (any language). Register from a client script:
exports.fiveprs:registerApp({
id = 'notes', label = 'Notes', color = '#0891b2', order = 600,
icon = 'M5 3h10l4 4v14H5z M9 9h6 M9 13h6',
page = ('https://cfx-nui-%s/html/index.html'):format(GetCurrentResourceName()),
})
AddEventHandler('fiveprs:appAction', function(app, action, data)
if app ~= 'notes' then return end
exports.fiveprs:sendAppMessage('notes', 'saved', { ok = true })
end)Leave out page and call exports.fiveprs:setAppView(id, screen) to have FivePRS draw a screen instead, using the same blocks as tables ({ blocks = { { type = 'section', title = 'Notes' }, ... } }). setAppBadge(id, text), setAppAvailable(id, bool) and unregisterApp(id) update the app, and apps are removed when their resource stops.
App pages. An app page includes https://cfx-nui-fiveprs/nui/app-sdk.js, which provides FivePRS.on(type, handler) for messages, FivePRS.action(name, data) to send an action to the app, FivePRS.home() to return to the home screen, and FivePRS.context, the player's FivePRS state (the same as exports.fiveprs:getState()), which is also delivered as a context message whenever it changes. Messages from a C# app's Send(type, payload) or a resource's sendAppMessage arrive through FivePRS.on. Escape inside an app page returns to the home screen.
The fiveprs_notes addon in the addons repository is a complete resource app to copy from.
The Duty app shows the player's rank and XP and lets them pick a department, agency and callsign before going on duty. Only departments the player is permitted to join are offered. Callsigns are up to 12 letters, numbers or hyphens, are saved to the player's profile, and must be unique among units on duty; leaving it blank uses the agency's default (for example LSPD-12). While on duty, the tab shows the player's unit and a Go off duty button.
On-duty units get a Dispatch app. It shows your unit and status, any incoming call with Accept and Decline buttons and a countdown, your active call with an End call button, every active call with its territory and assigned units, and all units on duty. From here you can set your status, attach to a call as backup and set a waypoint to a call. The AI callouts switch in the Settings app stops dispatch offering you AI callouts while player 911 calls still reach you, for servers that mix player and NPC roleplay; the choice is remembered, and /er_aicallouts toggles it (bindable under FivePRS in the key bindings). The accept, decline and end call keys still work alongside the buttons.
The menu lives in nui/ as plain HTML, CSS and JavaScript, so it can be restyled without rebuilding the resource.
On-duty police get a Records app. Search for a person by name or a vehicle by plate to open their record: identity, an active-warrant flag, licenses, registered vehicles and history. From a record, officers can:
- add a citation (with a fine up to
maxFineinconfig/settings.json), arrest, warning or warrant; - mark an active warrant as served or cleared;
- issue, suspend, revoke or reinstate any license type, including ones that are not self-service;
- mark a registered vehicle stolen or recovered.
Every change is stamped with the officer's name and callsign and written to the audit log. If the person's owner is online, they get a notification and their Characters app updates. A character with an active warrant cannot be deleted.
On duty as police, with your emergency lights on, get behind an AI-driven vehicle and press Left Shift to pull it over. Walk up to the driver and press E to ask for ID, run the plate, have them step out, search them, issue a warning or citation, serve a warrant, record an arrest or release them. AI drivers get a generated identity (name, date of birth, license status and sometimes a warrant) that is saved the first time it's checked, so citations and arrests show up in Records. Offences and fines are in config/civilian/citations.json; fines are capped at maxFine.
On foot, face any pedestrian and press E to stop them. The same menu opens without the vehicle actions. People and vehicles that belong to an active callout can't be stopped this way.
Every player has three civilian apps for roleplay records, all for their active character:
- Characters: create up to
maxCharacterscharacters (name, date of birth, gender) and pick the active one. Deleting a character removes its licenses and vehicles. - Licenses: license types come from
config/civilian/licenses.json. Types with"selfService": truecan be applied for from the tab and are issued immediately; others must be issued by law enforcement. Licenses can be valid, suspended or revoked. - Record: a read-only history of citations, arrests, warnings and warrants added by law enforcement.
- Vehicles: sit in the driver's seat and register the vehicle; the server reads the plate from the vehicle itself, so registrations always match a real car. Each character can register up to
maxVehiclesPerCharactervehicles, plates are unique server-wide, and owners can report a vehicle stolen or recovered.
maxCharacters and maxVehiclesPerCharacter are set in config/settings.json.
Appearance: each character has its own look. Creating a character opens the character creator, and Edit appearance on the Characters app reopens it (off duty only). Players build a custom male or female character (parents, face shape, hair, facial details, eye colour and clothing), or pick one of the standard GTA peds listed under creator.standardPeds in config/settings.json (set creator.allowStandardPeds to false to require custom characters). The look is saved per character, reapplied on every spawn and character switch, and restored when going off duty. Locker uniforms need a custom character; standard peds get the department's fallbackPedModels instead.
Every player has a 911 app to call Police, EMS or Fire from their current position, optionally as an anonymous caller. On-duty units in that department are notified and see the call in their Dispatch app with the caller and description; it has no primary unit, and any unit can attach to respond. The caller is told when units respond and when the call is cleared, and can cancel it while it is open. An attached unit clears the call from the Dispatch app when finished.
Each player can have one open 911 call at a time, with emergencyCallCooldownSeconds between calls. A call that nobody attaches to closes after emergencyCallTimeoutMinutes.
Players with fiveprs.admin get an Admin app. It lists online players and can search offline players by name, with buttons to add or remove each player from the Police, EMS and Fire rosters. Changes apply immediately: the player is notified, their department options update, and anyone removed from the department they are on duty in is taken off duty. Every change is written to the audit log.
The roster only takes effect when fiveprs_restrict_departments is true; the tab shows a warning while it is off.
Other client resources can read the local player's FivePRS state with exports.fiveprs:getState(). It returns name, onDuty, department and rank. While on duty, it also returns agency, callsign, status and territory, plus callId and call while assigned to a call. The official fiveprs_presence addon uses it for Discord rich presence.
FivePRS checks the core repository's releases on start and every checkIntervalHours. When a newer version is out, the console shows it with a summary of the release notes, and admins are told when they join. Run fiveprs_update in the server console (or in game with fiveprs.admin) to download the release and unpack it into data/updates/<version>/, without its config/ and data/ folders. Stop the server, copy that folder's contents over resources/fiveprs, and start it again; your settings and database are kept. If the new version changes the database, FivePRS updates it on start and logs each step (Applied database migration ...). With SQLite it first saves a copy to data/backups/; with MySQL, back up the database yourself before updating.
Settings are under updates in config/settings.json: checkForUpdates, repository, assetName (the release file to download, fiveprs.zip), checkIntervalHours and includePreReleases.
To publish a release, move the Unreleased entries in CHANGELOG.md under a new version heading, set the same version in fxmanifest.lua, commit, and push a tag named v<version>. GitHub Actions checks the versions match, builds and tests, and creates the release with fiveprs.zip attached and that changelog section as its notes. Versions with a suffix, like 0.9.0-ptb.1, are published as pre-releases, and servers running a pre-release are offered newer pre-releases automatically.
Fire (LSFD) and EMS (SAMS) are playable departments. Go on duty at a fire station or hospital like police do.
- Fire callouts (Vehicle Fire, Brush Fire) start real fires that spread until they're put out with the extinguisher or the fire engine's water cannon.
- EMS callouts (Medical Emergency, Traffic Collision) have a patient to treat with
E, load into the ambulance withE, and drive to the nearest hospital. - Equipment and vehicles are in
config/departments/fire/loadouts.json,config/departments/fire/vehicles.json,config/departments/ems/loadouts.jsonandconfig/departments/ems/vehicles.json, in the same format as the police files. Uniforms default to GTA's firefighter and paramedic peds; swap in freemode outfits if your server uses custom characters.
When a player dies they stay down where they fell instead of respawning, and EMS gets an automatic 911 call. On-duty EMS revive them with E; after respawnSeconds the player can press E to respawn at the nearest hospital. Admins can use fprs_revive <player id>. Settings are under death in config/settings.json: enabled, respawnSeconds, notifyEms and reviveXp. Turn it off if you use another death script.
On-duty units can request backup at Code 2 or Code 3 from the stop menu, with /backup [2|3] [npc|players], or with a key bound under FivePRS in the key bindings; /backup cancel ends the request. Any unit alerts on-duty players and sends an NPC unit if nobody attaches in time (or after a few seconds when nobody else is on duty), NPC unit sends one straight away for roleplay with NPCs, and Players only never sends one. On a call, backup is requested for that call; otherwise a Backup Request call is created at the officer's position. Police and the requester's own department are alerted with a notification and a flashing marker. Settings are under backup in config/settings.json: enabled, cooldownSeconds, npcEnabled, npcWaitSeconds, npcVehicle, npcPedModel and npcCrew.
FivePRS turns off wanted levels and GTA's own AI police, ambulance and fire response, so they don't interfere with roleplay. Set these under world in config/settings.json: disableWantedLevel and disableDispatchServices (both true by default) and disableRandomCops (false by default; true also stops ambient AI police from spawning).
Each player can only send so many requests to the server in a short time, so one player can't flood dispatch, records or the database. Requests over the limit are ignored, the player is told to slow down where it matters (911 calls, records, civilian actions), and the console logs the first one in each window. Limits are under rateLimits in config/settings.json, as a limit per perSeconds for each kind of request; set enabled to false to turn them off.
Players are returned to where they last were when they join, with their last character active. Positions are saved every saveIntervalSeconds while playing and when they leave. Turn it off with spawn.restoreLastLocation in config/settings.json.
The terminal nameplate, the notification logo, the server icon and the department icons are loaded from the FivePRS CDN. The URLs live under branding in config/settings.json and can point to your own images. The department icons under branding.departments (police, ems, fire and civilian) are shown in the Duty, Dispatch, Characters and 911 apps and in the station menu; a missing image is simply left out. The default terminal wallpapers are served from https://cdn.fiveprs.org/fiveprs/wallpapers/.
The server icon is downloaded on start and cached in data/server_icon.png, which is used if the download fails. It is only applied when fiveprs_server_icon is true, no icon has been loaded with load_server_icon, and server.cfg allows FivePRS to run the command with add_ace resource.fiveprs command.load_server_icon allow.
FivePRS hands each joining player's name, agency and rank to the loading screen. The official fiveprs_loadscreen addon in the addons repository uses it for a welcome back card; any loading screen can read it from window.nuiHandoverData.fiveprs.
config/world/stations.json lists the police stations, fire stations and hospitals. Each has a map blip and a duty point marker. Set blips to always, onDuty (only your own department's stations while on duty) or off.
| Field | Description |
|---|---|
id, name |
Unique ID and display name |
department |
Police, EMS or Fire |
agencies |
Agency IDs that use the station; empty means every agency in the department |
dutyPoint, heading |
Marker position [x, y, z], also where players teleport to |
armory, locker, garage |
[x, y, z] markers for each service. Without garage, the first parking spot or the pavement by the nearest road is used. Without armory or locker, that service is offered at the duty point instead |
parking |
Optional vehicle spots [x, y, z, heading]; the first free one is used, otherwise the nearest road to the garage |
blip |
Optional { "sprite": 60, "color": 3 } to override the department's default blip |
Each service has its own marker for on-duty members of the station's department; Mission Row ships with its armory, locker room and garage set. Pressing E (FivePRS: Interact) on a marker opens it. On the duty point it opens the Duty app, or the station menu while on duty. The station menu sits on the right of the screen and is used with the arrow keys or mouse wheel, Enter and Backspace:
- Armory: rank kits from
config/departments/police/loadouts.json(Recruit, Officer, Senior Officer and Command, unlocked by the tier of your rank inranks.json), each weapon on its own, body armour, ammo refills and returning weapons. A weapon can set alabelto change its menu name. - Locker: the patrol uniform, the command uniform for command-tier ranks, and your own clothes. Uniforms are freemode clothing; players using a standard GTA ped get
fallbackPedModelsfromconfig/departments/police/loadouts.json(the GTA police officer models by default) instead. - Garage: every model from
config/departments/police/vehicles.jsonyour rank unlocks, parked outside, and returning your vehicle when it is near the garage. You have one vehicle at a time.
To get coordinates, stand where you want a point and run /fprs_coords for a duty point, or /fprs_coords armory, locker or garage. Sit in a parked vehicle for a parking spot. The values are copied to the clipboard in config/world/stations.json format and printed to the F8 console.
When going on duty, the Duty app asks where to start:
- Here: your rank's loadout, uniform and vehicle are issued. The vehicle spawns on the nearest road, or outside the station if you are within 75 m of one of your stations.
- Station: you are teleported to the chosen station to collect your gear.
- Drive to station: a GPS route is set to the chosen station to collect your gear.
dutyEquipment in config/settings.json changes this: byStart (the default) works as above, always issues gear on every start (with Drive to station, the vehicle appears when you get close), and station never issues gear automatically.
config/world/jurisdictions.json defines territories as map polygons and the agencies that patrol them. Players choose an agency within their department from the duty menu, and dispatch only offers calls to units inside their agency's territory. An agency with no territories is unrestricted. The bundled split (Los Santos for LSPD, Blaine County for BCSO) is a coarse default; adjust the polygons to suit your server.
config/departments/police/loadouts.json and config/departments/police/vehicles.json define the default weapons, uniforms and patrol vehicles per rank tier. Any agency can override individual tiers under agencies; anything not overridden falls back to the defaults. BCSO ships with the sheriff and sheriff2 vehicles.
Vehicles spawn as stock models. A tier can also set primaryColor, secondaryColor, livery, dirtLevel, plateText, forcedExtras and disabledExtras; anything left out is not changed.
Uniforms use freemode clothing slots by default, which keeps the player's character. To dress an agency in a ped model instead:
"agencies": {
"bcso": {
"uniform": { "pedModels": { "male": "s_m_y_sheriff_01", "female": "s_f_y_sheriff_01" } }
}
}The original model and clothing are restored when going off duty, but freemode facial customisation is not, so ped models suit servers that do not use freemode characters.
Duty changes, department changes, XP awards, rank-ups, admin actions and denied permission checks are recorded in the fiveprs_audit table.
oxmysql isn't installed / oxmysql couldn't connect to the database. With fiveprs_db_type "mysql", FivePRS needs oxmysql started before it and mysql_connection_string set. oxmysql prints its own message explaining connection failures just above the FivePRS one.
Access to the path … is denied. The server's user account can't write to resources/fiveprs. On Linux, chown -R <server user> resources/fiveprs.
MissingMethodException, SecurityException or P/Invoke is not allowed on startup. The server is running FiveM for GTA V Enhanced, which FivePRS doesn't support yet. Use a GTA V Legacy server.
Could not load native SQLite or DllNotFoundException: e_sqlite3. The resource's server/ folder must contain e_sqlite3.dll (Windows) or libe_sqlite3.so (Linux). Re-extract fiveprs.zip rather than copying individual DLLs.
